4 Safety Handbook - SIL2
For the development of a function with a required safety integrity level SIL 2, this document lists measures for avoiding systematic failures during PHASE 1 up to PHASE 7.
SIL2 Required Safety Integrity SIL 2
MANAGEMENT/GENERAL
Independent of development (System, HW or SW) the following rules have to be followed for development in compliance with required SIL 2:
- Project management
- Definition of actions and responsibilities; scheduling and resource allocation
- Safety planning
- Definition of methods, techniques, actions and responsibilities; training of relevant personnel; consistency checks after modifications
- Modification
- Impact analysis
- Re-verify changed modules
- Re-verify affected modules, by regression tests
- Regression validation
- Configuration management
- Data recording and analysis [A7]
- Documentation
- Graphical and natural language, e.g., block diagrams, or flow diagrams.
SYSTEM & HARDWARE – PHASE 1 to 7
PHASE 1 - Requirements definition
- Requirements Spec.
PHASE 1 - Verification activities:
Task: to verify the correctness and completeness of the output documents of PHASE 1
Technique/Measure:
- Inspection of the specification
- The safety requirement specification shall be inspected by an independent person or organization.
- The checklist “Review of Safety Requirement Specification; “Checklist for Reviews” ref [A8].
- → No specific guidance document.
Test equipment to be used:
- Checklist
- No test equipment for this phase. The only equipment used is the “Checklist for Reviews” ref [A8], checklist “Review of Safety Requirement Specification”
Test documentation:
Further details of validation tests to be performed shall be described in a test plan
- Validation test descriptions: Product Type Test Description (PTTD)
PHASE 2 - Analysis and functional design
- Architecture
- Separation of safety and non-safety E/E/PE [A6]
- Modularization HW (modular design) [A6]
- Observance of guidelines and standards [A6]
- FPGA development according to FPGA Verification Methodology ref [A24].
- Structured specification [A6]
- Structured design, e.g., Reuse of tested circuit parts; [A6]
- Structured methods (used for FPGA) [A6]
Selected measures (from a group of recommended measures): - Use of well-tried components (Component standard)
PHASE 2 – Verification activities
The measure “Control and Data flow analysis” required by the standard is replaced by the measures of System-FMEA and SW-HAZOP based on UML. The following described techniques shall be used to verify the correctness and completeness of the output documents of this phase:
Technique/Measure:
- Inspection of the specification
- The safety system architecture specification shall be inspected by an independent person.
- The control architecture description shall be inspected by an independent person.
- → Refer “Checklist for Reviews” ref [A8]. The checklist for review of DoF is used.
- → See ref [A34] ABB approach to avoid common cause failures in PM/ SM where the different strategy is described.
- Checklists
- Prepared checklists shall be used concentrating on all safety-critical issues.
- → Refer “Checklist for Reviews” ref [A8].
- System FMEA
- To analyze a system design, by examining all possible sources of failure of a system's components and determining the effects of these failures on the behavior and safety of the system.
- → Refer “Checklist for Reviews” ref [A8]. The checklist for review of DoF is used.
Test documentation:
Describe the details of tests to be performed in the test plan.
- Verification test specification
- Function/Component Type Test Descriptions
- Integration Plan
- Specifies: who, what, and when shall be integrated.
- Consider: projects, related groups, teams, and programs.
- Internally within teams: use project or team descriptions for this purpose
- Product Tests
- Details in the test plan
- Environmental Tests
- Climatic, mechanical and EMC (RFI; EMC; EMI)
- Electrical safety tests
- -
- Integration test descriptions
- Low-level integration test descriptions.
- Functional test descriptions
- Functional Test Descriptions.
PHASE 3 - Detailed design
- Architecture
- Observance of guidelines and standards [A6]
- Separation of safety and non-safety E/E/PE [A6]
- Modularization HW (modular design) [A6]
- Use of well-tried components (Component standard)
- Structured specification [A6]
- Structured design [A6]
- Graceful degradation [A6]
- Semi-formal methods (for FPGA) [A6]
- Program sequence monitoring [A6]
- Detailed Design
- Structured and modularized HW (modular design)
- Observance of guidelines and standards [A6]
- De-rating for hardware components
- Use of well-tried components (Component standard)
PHASE 3 – Verification strategies and techniques
Task: to verify the correctness and completeness of the output documents of this PHASE 3:
Technique/Measure:
- Checklists
- Prepared checklists for all documented outputs of safety lifecycle phases shall be used concentrating on all safety-critical issues.
- → Refer “Checklist for Reviews” ref [A8].
- Inspection or walkthrough
- Design descriptions shall be walked-through including a person independent of the design.
- → See ref [A34] ABB approach to avoid common cause failures in PM/ SM where the different strategy is described.
Test equipment to be used:
- Checklist (→ “Checklist for Reviews” ref [A8]).
Test documentation:
Describe details of design tests to be performed in the test plan:
- Integration test descriptions (Low-level integration test descriptions)
- Design test descriptions (Design Test Descriptions)
PHASE 4 – Implementation / Manufacturing
- Implementation
- FPGA development according to FPGA Verification Methodology ref [A24].
- Hardware FMEDA
PHASE 4 - Verification activities:
Task: to verify the correctness and completeness of the output documents of PHASE 4:
Technique/Measure:
-
Hardware FMEDA including determination of the SFF
- To rank the criticality of components that could result in injury, damage or system degradation through single-point failures, in order to determine which components might need special attention and necessary control measures during design or operation.
- → “ABB approach to IEC61508 failure classification and probability calculations for AC 800M HI” ref [A38]
-
PFD calculation
- The PFD calculation shall be based on typical conditions.
- → “ABB approach to IEC61508 failure classification and probability calculations for AC 800M HI” ref [A38]
-
Analysis
- for VHDL follow FPGA Verification Methodology ref [A24].
Test equipment to be used:
- Checklist (→ “Checklist for Reviews” ref [A8]).
- Hardware FMEDA (→ Analysis tools for the FMEDA.)
- Analysis for VHDL (→ according to FPGA Verification Methodology [A24]).
PHASE 5 – Module/Design and low-level integration test
- Module Testing
- FPGA development according to FPGA Verification Methodology ref [A24].
- Functional testing.
PHASE 6 – Function/Component type test
- Integration Testing
PHASE 7 – Validation PTT/STT
- Validation
- Functional testing
- Functional testing under environmental conditions [A7]
- Interference surge immunity testing [A7]
- Expanded functional testing [A7] (Test that all safety functions are maintained in the case of static input states and/or change over situations and/or unusual input changes, caused by faulty process or operating conditions)
- Fault insertion testing, when required by the FMEDA (diagnostic coverage >= 90%) [A7]
Selected measures (from a group of recommended measures): - Static/dynamic analysis and failure analysis [A7].
SOFTWARE – PHASE 1 to 7
PHASE 1 - Requirements definition
- Requirements Spec.
PHASE 1 - Verification activities:
Task: to verify the correctness and completeness of the output documents of PHASE 1
Technique/Measure:
- Inspection of the specification
- The safety requirement specification shall be inspected by an independent person or organization.
- The checklist “Review of Safety Requirement Specification; “Checklist for Reviews” ref [A8].
- → No specific guidance document.
Test equipment to be used:
- Checklist
- No test equipment for this phase. The only equipment used is the “Checklist for Reviews” ref [A8], checklist “Review of Safety Requirement Specification”
Test documentation:
Further details of validation tests to be performed shall be described in a test plan
- Validation test descriptions: Product Type Test Description (PTTD)
PHASE 2 - Analysis and functional design
- Architecture
- Separation of safety and non-safety software [A6]
- Modular approach SW (modular design) [A6]
- Semi-formal methods [A6]
- Use of trusted/verified software elements (if available) [A6]
- No dynamic reconfiguration (to the extent applicable to PLC) [A6]
- Diverse monitor techniques (external monitor) [A6]
- Cyclic behavior, with guaranteed maximum cycle time [A6]
Selected measures (from a group of recommended measures): - Computer-aided design tools [A6]
- Fault detection and diagnosis [A6]
- High-Level Design
PHASE 2 – Verification activities
The measure “Control and Data flow analysis” required by the standard is replaced by the measures of System-FMEA and SW-HAZOP based on UML. The following described techniques shall be used to verify the correctness and completeness of the output documents of this phase:
Technique/Measure:
- Inspection of the specification
- The safety system architecture specification shall be inspected by an independent person.
- The control architecture description shall be inspected by an independent person.
- → Refer “Checklist for Reviews” ref [A8]. The checklist for review of DoF is used.
- → See ref [A34] ABB approach to avoid common cause failures in PM/ SM where the different strategy is described.
- Checklists
- Prepared checklists shall be used concentrating on all safety-critical issues.
- → Refer “Checklist for Reviews” ref [A8].
- System FMEA
- To analyze a system design, by examining all possible sources of failure of a system's components and determining the effects of these failures on the behavior and safety of the system.
- → Refer “Checklist for Reviews” ref [A8]. The checklist for review of DoF is used.
- Software Safety Criticality analysis
- To determine safety hazards in the proposed system architecture, their possible causes and consequences, and recommend action to minimize the chance of their occurrence. → Refer “SW HAZOP Guideline” ref [A51].
Test documentation:
Describe the details of tests to be performed in the test plan.
- Verification test specification
- Function/Component Type Test Descriptions
- Integration plan
- Specifies: who, what, and when shall be integrated.
- Consider: projects, related groups, teams, and programs.
- Internally within teams: use project or team descriptions for this purpose
- Product Tests
- Details in the test plan
- Software safety criticality analysis
- Analysis tools for the HAZOP.
- Integration test descriptions
- Low-level integration test descriptions.
- Functional test descriptions
- Functional Test Descriptions.
PHASE 3 - Detailed design
- Architecture
- Design and coding standards [A6]
- Separation of safety and non-safety software [A6]
- Modular approach SW (modular design) [A6]
- Semi-formal methods [A6]
- Tools and translators with increased confidence from use [A6]
- No dynamic reconfiguration [A6]
- Modification protection [A6]
- Diverse monitor techniques (external monitor) [A6]
- Use of trusted/verified software elements (if available) [A6]
Selected measures (from a group of recommended measures): - Assertions
- Computer-aided design tools [A6]
- Fault detection and diagnosis [A6]
- Detailed design
- Modular approach SW (modular design) [A6]
- Semi-formal methods [A6]
- Tools and Translators with increased confidence from use [A6]
- Program sequence monitoring [A6]
- Structured programming [A6]
- Design and coding standards [A6]
- Computer-aided design tools [A6]
- Modification protection [A6]
- Use of trusted/verified software elements (if available) [A6]
Selected measures (from a group of recommended measures): - Fault detection and diagnosis [A6]
PHASE 3 – Verification strategies and techniques
Task: to verify the correctness and completeness of the output documents of this PHASE 3:
Technique/Measure:
- Checklists
- Prepared checklists for all documented outputs of safety lifecycle phases shall be used concentrating on all safety critical issues.
- → Refer “Checklist for Reviews” ref [A8].
- Inspection or walkthrough
- Design descriptions shall be walked-through including a person independent of the design.
- → See ref [A34] ABB approach to avoid common cause failures in PM/ SM where the different strategy is described.
- Detailed SW HAZOP analysis
- To determine safety hazards in the proposed design, their possible causes and consequences, and recommend action to minimize the chance of their occurrence.
- → (No specific guidance document)
Test equipment to be used:
- Checklist (→ “Checklist for Reviews” ref [A8]).
- HAZOP (→ Analysis tools for the HAZOP).
Test documentation:
Describe details of design tests to be performed in the test plan:
- Integration test descriptions (Low-level integration test descriptions)
- Design test descriptions (Design Test Descriptions)
PHASE 4 – Implementation / Manufacturing
- Implementation
- Tools
- Use of tools with increased confidence from use
PHASE 4 - Verification activities:
Task: to verify the correctness and completeness of the output documents of PHASE 4:
Technique/Measure:
- Static code analysis
- Code review
- Refer to section Code Reviews.
Test equipment to be used:
- Checklist (→ “Checklist for Reviews” ref [A8].)
- PC-Lint (→ Static code analysis tool)
PHASE 5 – Module/Design and low-level integration test
- Module Testing (ABB: Module/Design and low-level integration Test)
- Functional and black box testing [A7]
- Equivalence classes and input partition testing (covers boundary value analysis) [A7]
- Data recording and analysis [A7]
- Test management and automation tools
- Dynamic analysis and testing [A7]
- Error guessing [A7]
- Equivalence classes and input partition testing (covers boundary value analysis) [A7]
- Structural test coverage if not planned for function test level. (White box testing):
- 100% entry points
- 100% statements
(Coverage measurement during the other tests might be an alternative)
- Test of sequence diagrams
- State machine testing [A7]
Selected measures (from a group of recommended measures): - Interface testing (by using the techniques under Functional and black box testing). [A7]
PHASE 6 – Function/Component type test
- Integration testing (ABB: Function/ Component Type Test)
- Functional and black box testing [A7]
- Test the behavior of the system for different inputs made by a user in a user interface
- Test the behavior of the system for different in and outputs to the function provided by other system parts
- Equivalence classes and input partition testing (covers boundary value analysis) [A7] (covered by low-level integration testing)
- Functional and black box testing [A7]
- Data recording and analysis [A7]
- Dynamic analysis and testing [A7]
- Performance testing – e.g. critical timing, max. load, max. configuration
PHASE 7 – Validation PTT/STT
- Validation
- Functional and black box testing [A7]
- Test cases defined on the requirement basis (validation objectives)
- Equivalence classes and input partition testing (covers boundary value analysis) (covered by integration testing) [A7]
- Data recording and analysis [A7]
Selected measures (from a group of recommended measures): - Simulation (wherever suitable as a validation method) [A7]
- Functional and black box testing [A7]
