For the development of a function with a required safety integrity level SIL 1, this document lists measures for avoiding systematic failures during PHASE 1 up to PHASE 7.

SIL1 Required Safety Integrity SIL 1

SIL1 - SIL1

MANAGEMENT/GENERAL

SIL1 - SIL1 - Gen

Independent of development (System, HW or SW) the following rules have to be followed for development in compliance with the required SIL 1:

  • Project management
    • Definition of actions and responsibilities; scheduling and resource allocation
  • Safety planning
    • Definition of methods, techniques, actions and responsibilities; training of relevant personnel; consistency checks after modifications
  • Modification
    • Impact analysis
    • Re-verify changed modules
    • Configuration management
    • Data recording and analysis [A7]
  • Documentation
    • Graphical and natural language, e.g., block diagrams, or flow diagrams.
SYSTEM & HARDWARE – PHASE 1 to 7

SIL1 - SIL1 - Sys

PHASE 1 - Requirements definition

  • Requirements specification
    • Structured specification, i.e., manual hierarchical separation into sub-requirements; description of the interfaces [A6]
    • Separation of safety and non-safety E/E/PE (This can be done by naming convention) [A6]

PHASE 1 - Verification activities:

Task: to verify the correctness and completeness of the output documents of PHASE 1

Technique/Measure:

  • Inspection of the specification
    • The safety requirement specification shall be inspected by an independent person or organization.
    • The checklist “Review of Safety Requirement Specification; “Checklist for Reviews” ref [A8].
    • → No specific guidance document.

Test equipment to be used:

  • Checklist
    • No test equipment for this phase. The only equipment used is the “Checklist for Reviews” ref [A8], checklist “Review of Safety Requirement Specification”

Test documentation:

Further details of validation tests to be performed shall be described in a Test Plan

  • Validation Test Descriptions
    • Product Type Test Description (PTTD)

PHASE 2 - Analysis and functional design

  • Architecture
    • Separation of safety and non-safety E/E/PE [A6]
    • Modularization HW (modular design) [A6]
    • Structured design, e.g., reuse of tested circuit parts; [A6]
    • Observance of guidelines and standards [A6]
    • FPGA development according to FPGA verification methodology ref [A24].
    • Semiformal method

PHASE 2 – Verification activities

The measure “Control and data flow analysis” required by the standard is replaced by the measures of System-FMEA and SW-HAZOP based on UML. The following described techniques shall be used to verify the correctness and completeness of the output documents of this phase:

Technique/Measure:

  • Inspection of the specification
    • The safety system architecture specification shall be inspected by an independent person.
    • The control architecture description shall be inspected by an independent person.
    • → Refer “Checklist for Reviews” ref [A8]. The checklist for review of DoF is used.
    • → See ref [A34] ABB approach to avoid common cause failures in PM/ SM where the different strategy is described.
  • Checklists
    • Prepared checklists shall be used concentrating on all safety-critical issues.
    • → Refer “Checklist for Reviews” ref [A8].
  • System FMEA
    • To analyze a system design, by examining all possible sources of failure of a system's components and determining the effects of these failures on the behavior and safety of the system.
    • → Refer “Checklist for Reviews” ref [A8]. The checklist for review of DoF is used.

Test documentation:

Describe the details of tests to be performed in the test plan.

  • Verification test specification
    • Function/Component type test descriptions
  • Integration plan
    1. Specifies: who, what, and when shall be integrated.
    2. Consider: projects, related groups, teams, and programs.
    3. Internally within teams: use project or team descriptions for this purpose
  • Product tests
    • Details in the test plan
  • Environmental tests
    • Climatic, mechanical and EMC (RFI; EMC; EMI)
  • Electrical safety tests
    • -
  • Integration test descriptions
    • Low-level integration test descriptions.
  • Functional test descriptions
    • Functional test descriptions.

PHASE 3 - Detailed design

  • Architecture
    • Observance of guidelines and standards [A6]
    • Separation of safety and non-safety E/E/PE [A6]
    • Modularization HW (Modular design) [A6]
    • Use of well-tried components (Component standard)
    • Structured specification [A6]
    • Structured design [A6]
    • Program sequence monitoring [A6]
  • Detailed design
    • Structured and modularization HW (modular design) [A6]
    • Observance of guidelines and standards [A6]
    • Use of well-tried components (component standard)
      Selected measures (from a group of recommended measures):
    • De-rating for hardware components, e.g. see also EN 298 for further guidance

PHASE 3 – Verification strategies and techniques

Task: to verify the correctness and completeness of the output documents of this phase 3:

Technique/Measure:

  • Checklists

    • Prepared checklists for all documented outputs of safety lifecycle phases shall be used concentrating on all safety critical issues.
    • → Refer “Checklist for Reviews” ref [A8]
  • Inspection or walkthrough

    • Design descriptions shall be walked-through including a person independent of the design.
    • For SIL3 Inspection, by an independent organization using a formal procedure
    • → See ref [A34] ABB approach to avoid common cause failures in PM/ SM where the different strategy is described.

Test equipment to be used:

  • Checklist (→ “Checklist for Reviews” ref [A8].)

Test documentation:
Describe details of design tests to be performed in the test plan:

  • Integration test descriptions (Low-level integration test descriptions)
  • Design test descriptions (Design Test Descriptions)

PHASE 4 – Implementation / Manufacturing

  • Implementation
    • FPGA development according to FPGA Verification Methodology ref [A24].
    • Hardware FMEDA

PHASE 4 - Verification activities:

Task: to verify the correctness and completeness of the output documents of PHASE 4:

Technique/Measure:

  • Hardware FMEDA including determination of the SFF
    • To rank the criticality of components that could result in injury, damage or system degradation through single-point failures, in order to determine which components might need special attention and necessary control measures during design or operation.
    • → “ABB_approach_to_IEC6108 failure classification and probability calculations for AC 800M HI” ref [A38]
  • PFD calculation
    • The PFD calculation shall be based on typical conditions.
    • → “ABB_approach_to_IEC6108 failure classification and probability calculations for AC 800M HI” ref [A38]
  • Analysis
    • for VHDL follow FPGA Verification Methodology ref [A24].

Test equipment to be used:

  • Checklist (→ “Checklist for Reviews” ref [A8].)
  • Hardware FMEDA (→ Analysis tools for the FMEDA)
  • Analysis for VHDL (→ according to FPGA Methodology [A24].)

PHASE 5 – Module/Design and low-level integration Test

  • Module Testing
    • FPGA development according to FPGA Verification Methodology ref [A24].
    • Functional testing.

PHASE 6 – Function/Component type test

  • Integration testing
    • Functional and black box testing [A7]
      Selected measures (from a group of recommended measures):
    • Field experience. [A7]

PHASE 7 – Validation PTT/STT

  • Validation
    • Functional testing
    • Functional testing under environmental conditions [A7]
    • Interference surge immunity testing [A7]
    • Fault insertion testing, when required by the FMEDA (diagnostic coverage >= 90%) [A7]
      Selected measures (from a group of recommended measures):
    • Static/dynamic analysis and failure analysis. [A7]
SOFTWARE – PHASE 1 to 7

SIL1 - SIL1 - SW

PHASE 1 - Requirements definition

  • Requirements specification
    • n/a (to be done before any criticality allocation)

PHASE 1 - Verification activities:

Task: to verify the correctness and completeness of the output documents of PHASE 1

Technique/Measure:

  • Inspection of the specification
    • The safety requirement specification shall be inspected by an independent person or organization.
    • The checklist “Review of Safety Requirement Specification; “Checklist for Reviews” ref [A8].
    • → No specific guidance document.

Test equipment to be used:

  • Checklist
    • No test equipment for this phase. The only equipment used is the “Checklist for Reviews” ref [A8], checklist “Review of Safety Requirement Specification”

Test documentation:

Further details of validation tests to be performed shall be described in a test plan

  • Validation test descriptions: Product Type Test Description (PTTD)

PHASE 2 - Analysis and functional design

  • Architecture
    • Separation of safety and non-safety software [A6]
    • Modular approach SW (modular design) [A6]
    • Structured methods [A6]
      Selected measures (from a group of recommended measures):
    • Use of trusted/verified software elements (if available) [A6]
    • Fault detection and diagnosis [A6]
  • High-level design
    • Design and coding standards [A6]
    • Modular approach SW (modular design) [A6]
    • Structured methods [A6]
      Selected measures (from group of Recommended measures):
    • Use of error-detecting codes (where applicable)

PHASE 2 – Verification activities

The measure “Control and Data flow analysis” required by the standard is replaced by the measures of System-FMEA and SW-HAZOP based on UML. The following described techniques shall be used to verify the correctness and completeness of the output documents of this phase:

Technique/Measure:

  • Inspection of the specification
    • The safety system architecture specification shall be inspected by an independent person.
    • The control architecture description shall be inspected by an independent person.
    • → Refer “Checklist for Reviews” ref [A8]. The checklist for review of DoF is used.
    • → See ref [A34] ABB approach to avoid common cause failures in PM/ SM where the different strategy is described.
  • Checklists
    • Prepared checklists shall be used concentrating on all safety-critical issues.
    • → Refer “Checklist for Reviews” ref [A8]
  • System FMEA
    • To analyze a system design, by examining all possible sources of failure of a system's components and determining the effects of these failures on the behavior and safety of the system.
    • → Refer “Checklist for Reviews” ref [A8]. The checklist for review of DoF is used.
  • Software safety criticality analysis
    • To determine safety hazards in the proposed system architecture, their possible causes and consequences, and recommend action to minimize the chance of their occurrence.
    • → Refer “SW HAZOP Guideline” ref [A51].

Test documentation:

Describe the details of tests to be performed in the test plan.

  • Verification test specification
    • Function/Component Type Test Descriptions
  • Integration plan
    1. Specifies: who, what, and when shall be integrated.
    2. Consider: projects, related groups, teams, and programs.
    3. Internally within teams: use project or team descriptions for this purpose.
  • Product tests
    • Details in the test plan
  • Software safety criticality analysis
    • Analysis tools for the HAZOP.
  • Integration test descriptions
    • Low-level integration test descriptions.
  • Functional test descriptions
    • Functional Test Descriptions.

PHASE 3 - Detailed design

  • Architecture
    • Design and coding standards [A6]
    • Separation of safety and non-safety software [A6]
    • Modular approach SW (Modular design) [A6]
    • Structured methods [A6]
    • Modification Protection [A6]
    • Tools and translators with increased confidence from use [A6]
      Selected measures (from a group of recommended measures):
    • Use of trusted/verified software elements (if available) [A6]
    • Assertions – e.g. for interfaces and control flow
    • Fault detection and diagnosis [A6]
  • Detailed design
    • Modular approach SW (modular design) [A6]
    • Semiformal methods
    • Tools and translators with increased confidence from use [A6]
    • Program sequence monitoring [A6]
    • Structured programming [A6]
    • Design and coding standards [A6]
      Selected measures (from a group of recommended measures):
    • Use of trusted/verified software elements (if available) [A6]
    • Fault detection and diagnosis [A6]

PHASE 3 – Verification strategies and techniques

Task: to verify the correctness and completeness of the output documents of this PHASE 3:

Technique/Measure:

  • Checklists
    • Prepared checklists for all documented outputs of safety lifecycle phases shall be used concentrating on all safety critical issues.
    • → Refer “Checklist for Reviews” ref [A8].
  • Inspection or walkthrough
    • Design descriptions shall be walked-through including a person independent of the design.
    • For SIL3 inspection, by an independent organization using a formal procedure
    • → See ref [A34] ABB approach to avoid common cause failures in PM/ SM where the different strategy is described.
  • Detailed SW HAZOP analysis
    • To determine safety hazards in the proposed design, their possible causes and consequences, and recommend action to minimize the chance of their occurrence.
    • → (No specific guidance document)

Test equipment to be used:

  • Checklist (→ “Checklist for Reviews” ref [A8].)
  • HAZOP (→ Analysis tools for the HAZOP.)

Test documentation:
Describe details of design tests to be performed in the test plan:

  • Integration test descriptions (Low-level integration test descriptions)
  • Design Test Descriptions (Design Test Descriptions)

PHASE 4 – Implementation / Manufacturing

  • Implementation
    • Modular approach SW (modular design) [A6]
    • Coding standards [A6]
    • Structured programming [A6]
    • Suitable, strongly typed programming language
      Selected measures (from a group of recommended measures):
    • Use of trusted/verified software elements (if available) [A6]
  • Tools
    • Use of tools with increased confidence from use

PHASE 4 - Verification activities:

Task: to verify the correctness and completeness of the output documents of PHASE 4:

Technique/Measure:

  • Static code analysis
    • → “Static Code Analysis Guideline” ref [A17]
    • → And for VHDL “FPGA Verification Methodology” ref [A24]
  • Code review

Test equipment to be used:

  • Checklist (→ “Checklist for Reviews” ref [A8].)
  • PC-Lint (→ Static Code Analysis Tool)

PHASE 5 – Module/Design and low-level integration test

  • Module testing (ABB: Module/Design and low-level integration test)
    • Functional and black box testing [A7]
    • Data recording and analysis [A7]
    • Dynamic analysis and testing [A7]
    • Error guessing [A7]
    • Structural test coverage if not planned for function test level. (White box testing):
      • 100% entry points (Coverage measurement during the other tests might be an alternative). [A7]

PHASE 6 – Function/Component type test

  • Integration testing (ABB: Function/ Component Type Test)Test)
    • Functional and black box testing [A7]

    • Data recording and analysis [A7]

    • Dynamic analysis and testing [A7]

      • Error guessing [A7]
      • Test of sequence diagrams (if part of the design)
      • State machine testing (if part of the design) [A7]

      Selected measures (from a group of recommended measures):

    • Performance testing (covered by the Function/ Component Type Tests which include timing tests and FTT covering Memory issues). [A7]

PHASE 7 – Validation PTT/STT

  • Validation
    • Functional and black box testing [A7]
    • Data recording and analysis [A7]

Owner: Functional Safety Team
