6 Safety Handbook - SIL - Library
For the development of a library with a required safety integrity level SIL 1, this document lists measures for avoiding systematic failures during PHASE 1 up to PHASE 7.
SIL Libraries according to IEC 61508 and IEC 61511
MANAGEMENT/GENERAL for Libraries according to SIL
- Project management
- Project monitoring; configuration management (CM), and software support tools for CM.
- Safety planning
- Definition of methods, techniques, actions and responsibilities; training of relevant personnel; consistency checks after modifications.
- Modification
- Impact analysis
- Re-verify changed modules
- Re-verify affected modules, by regression tests
- Revalidate the complete system or
- Regression validation
- Configuration management
- Data recording and analysis [A7]
- Forward traceability between SW safety requirements and the SW modification plan [A37]
- Backward traceability between SW modification plan and SW safety requirements [A37]
- Documentation
- Graphical and natural language descriptions, e.g. block diagrams, flow diagrams.
- Guidelines for consistent content; computer-aided documentation management, and formal change control.
Libraries – SIL – PHASE 1 to 7
PHASE 1 - Requirements definition
- N/A
PHASE 1 - Verification activities:
- N/A
PHASE 2 - Analysis and functional design
- Architecture
- High-level design
- Design and coding standards [A6]
- Modular approach SW (modular design) [A6]
- Structured methods [A6]
- Structured design, e.g., reuse of well-proven components. [A6]
- Fault detection and diagnosis [A6]
- Computer aided design tools [A6]
- Modularity of functionality;
- Testability of functionality (including fault-tolerant features) and of internal structure;
- The capacity for safe modification;
- Traceability to, and explanation of, application functions and associated constraints. [A37]
NOTE: Wherever possible proven software modules should be used.
PHASE 2 – Verification activities
The measure “Control and Data flow analysis” required by the standard is replaced by the measures of System-FMEA and SW-HAZOP based on UML. The following described techniques shall be used to verify the correctness and completeness of the output documents of this phase:
Technique/Measure:
-
Inspection of the specification
- The safety system architecture specification shall be inspected by an independent person.
- The control architecture description shall be inspected by an independent person.
- → Refer “Checklist for Reviews” ref [A8]. The checklist for review of DoF is used.
- → See ref [A34] ABB approach to avoid common cause failures in PM/ SM where the different strategy is described.
-
Checklists
- Prepared checklists shall be used concentrating on all safety-critical issues.
- → Refer “Checklist for Reviews” ref [A8].
Test documentation:
Describe the details of tests to be performed in the test plan:
- Verification test specification
- Function/Component Type Test Descriptions
- Integration plan
- Specifies: who, what, and when shall be integrated.
- Consider: projects, related groups, teams, and programs.
- Internally within teams: use project or team descriptions for this purpose
- Product tests
- Details in the Test Plan
- Integration test descriptions
- Low-level integration test descriptions.
- Functional test descriptions
- Functional Test Descriptions.
PHASE 3 - Detailed design
- Architecture
- Detailed design
- Modular approach SW (Modular design) [A6]
- Structured methods [A6]
- Tools and translators with increased confidence from use [A6]
- Design and coding standards [A6]
Selected Measures (from a group of recommended measures): - Use of trusted/verified software elements (if available) [A6]
- Computer-aided tools
- Fault detection and diagnosis [A6]
- Modification protection [A6]
- Defensive programming [A6]
- Plausibility checks of each input variable including any global variables used to provide input data;
- A full definition of input and output interfaces;
The application software should: - Be readable, understandable and testable;
- Satisfy the relevant requirements specified during safety planning
PHASE 3 – Verification strategies and techniques
Task: to verify the correctness and completeness of the output documents of this PHASE 3:
Technique/Measure:
- Checklists
- Prepared checklists for all documented outputs of safety lifecycle phases shall be used concentrating on all safety critical issues.
- → Refer “Checklist for Reviews” ref [A8].
- Inspection or walkthrough
- Design descriptions shall be walked-through including a person independent of the design.
- For SIL3 inspection, by an independent organization using a formal procedure
- → See ref [A34] ABB approach to avoid common cause failures in PM/ SM where the different strategy is described.
Test equipment to be used:
- Checklist (→ “Checklist for Reviews” ref [A8].)
Test documentation:
Describe details of design tests to be performed in the test plan:
- Integration Test Descriptions
- Low-level integration test descriptions
- Design Test descriptions
- Design Test Descriptions
PHASE 4 – Implementation / Manufacturing
- Implementation
- Design guideline
- Modular approach SW (modular design) [A6]
- Coding standards [A6]
- Structured programming [A6]
- Suitable, strongly typed programming languages
- Defensive programming [A6]
- Forward traceability between the software safety requirements specification and software design [A37]
Selected Measures (from a group of recommended measures): - Use of trusted/verified software elements (if available) [A6]
- Tools
- Use of 'confidence-from-use' tools
For more explanation of the above-mentioned techniques, measures and related Guidelines refer to the ABB approach to IEC 61508 2nd Ed Design ref [A6] and ABB Approach to IEC 61508 Traceability [A37].
PHASE 4 - Verification activities:
Task: to verify the correctness and completeness of the output documents of PHASE 4:
Technique/Measure:
- Static code analysis
- Code review
- Refer to section Code Reviews.
Test equipment to be used:
- Checklist (→ “Checklist for Reviews” ref [A8]).
- PC-Lint** (→ static code analysis tool)
PHASE 5 – Module/Design and low-level integration Test
- Application module testing
- Test of intended function (unintended functions are not executed) from input points to output points
- Forward traceability between the Description of Function and the module and integration test specifications [A37]
- Functional and black box testing [A7]
- Equivalence classes and input partition testing (covers boundary value analysis) [A7]
- Simulation (e.g. for elements that need feedback from the equipment under control, like controllers, or timing effects due to the sequence of execution.) [A7]
- Review techniques
Related Guidelines: ABB approach to IEC 61508 2nd Ed Test ref [A7], ABB Approach to Code Coverage Analysis [A47] and ABB Approach to IEC 61508 Traceability [A37].
PHASE 6 – Function/Component Type Test
- Integration testing (ABB: Function/ Component Type Test)
- Automated test, when applicable
- Forward traceability between the system and software design requirements for hardware/software integration and the hardware/software integration test specifications [A37]
- Functional and black box testing [A7]
- Equivalence classes and input partition testing (covers boundary value analysis) [A7]
- Structural test coverage (White box testing) [A7]
- Data recording and analysis [A7]
- Interface testing (if not covered by functional and black box testing) [A7]
- Performance testing [A7]
Related guidelines: ABB Approach to Test of Library Types ref [A35] and ABB Approach to IEC 61508 Traceability [A37].
PHASE 7 – Validation PTT/STT
- Validation
- Functional test based on the requirements
- Functional and black box testing [A7]
- Test cases defined on the requirement basis (validation objectives)
- Equivalence classes and input partition testing (covers boundary value analysis) (covered by integration testing: FTT) [A7]
- Data recording and analysis [A7]
- Simulation / modelling [A7]
Related guidelines: ABB approach to IEC 61508 2nd Ed Test ref [A7].
